| Direction of Rotation | CW |
|---|---|
| Output Torque (Nm) | 1.8 |
| Max Rotation Time per Cycle (s) | 0.5 (based on 24-division model) |
| Backlash (arcmin) | - |
| Repeatability (mm) | ±0.01 |
| Lubrication | Not required (Lubrication-free) |
| Options | N = None (pneumatic drive type), M = Motor drive type (to be released) |
| Power Source | Pneumatic (or DC 24V single power) |
| Max Operating Pressure (MPa) | 1.0 |
| Weight (lb/oz) | 2.1 / 33.6oz |
